Experience Lights Genius Pro 16 Build
$795.00$629.00
- Description
- Specifications
New in the 2024 Edition:
- RJ45 jacks changed from plastic to stronger Metal RJ45.
- USB jack changed from USB Micro to USB-C.
- Holes widened for easier mounting.
- eFuses adjusted for additional leniancy, and auto-retry.
- Rotary dial updated to have "detents" that click while you spin for better control.
Features:
- Patent Pending Genius Mounting System, to mount 1 or 2 power supplies directly to the circuit board
- 2 x 6" black wire and 2 x 6" red wire with connectors pre-attached to the ends for quick power supply hookup
- Rotary knob for navigating menus on the OLED display
- 1 Ethernet Port
- Pre-defined hole patterns to fit neatly into an NBF-32022 bud box, CG-1500, or Your Pixel Store Medium Box (WC-004-2) enclosure
- 16 x 3-pin, extra large, color coded Clever LockTM connectors (no phoenix connectors or screw down terminals)
- Original eFuse design, with configurable per port on/off power control.
- Max 4A per output.
- Supported protocols: DDP, E1.31, ArtNet
- Outputs the most common 3-wire WS281X pixel protocol
- Full range 5V-24V
- 2 x RJ45 ports for long range receivers
- 2 x RJ45 ports for DMX output
- Configuration can be done via your smartphone, tablet or PC over a wifi or wired connection
- Per port current monitoring (RTCM: Real time current Monitoring)
- Per port pixel counting
- SD card slot for standalone operation or to operate as FPP remote.
- Simple & fast over-the-air updates; with ability to easily roll back to previous firmware versions
- Rich JSON API
- Built-in test mode animations
- Seamlessly control up to ~10,000 pixels using e1.31/artnet, or ~20,000 pixels using DDP
- No banks or groups. Pixels can be distributed however you'd like on any outputs, with any number of pixels assigned to each port
